Pioneer GM-D9705 5 Channel Amplifier With Wired Bass Boost Remote

Key Features

• 5 Channel Champion Series Class D Amplifier w/ Wired Bass Boost Remote
• Total power output: 2000 watts Max
• Wired remote bass boost level control included
• Speaker-level (high-level) inputs
• 5, 4 or 3 channel operation
• Dedicated, large-block subwoofer terminal output

Pioneer GM-D9705 Class-D 5-Channel Amplifier with Wired Bass Boost Remote produces impressive power in an all-in-one solution designed to deliver big sound without sacrificing space. Ideal for any vehicle including compact vehicles and pick-up trucks with limited real estate, the GM-D9705 also offers installation flexibility for a variety of other applications. The 5-channel amplifier Wired Bass Boost Remote is rated at 2000 watts max with the A and B channels rated at 75 watts x 4 (RMS) and the subwoofer output rated at 600 watts at 2 (RMS). Compared to similarly priced multichannel amplifiers Wired Bass Boost Remote, the variable crossover networks on the GM-D9705 offer increased flexibility and give listeners more control. Block terminals for a cleaner installation and direct wire contact minimizing resistance.

For extra flexibility, a variable LPF makes audio frequency more adjustable according to subwoofer characteristics and personal listening preferences. The GM-D9705 LPF is adjustable from 40 Hz to 240 Hz. The GM-D9705 also features a Bass Boost Remote for optimal bass level adjustment according to listening preferences and music characteristics. What, you DON’T own a Pioneer head unit? Well, we won’t hold it against you. In fact we’ll even help you build onto your system. The GM-D9705’s speaker level inputs allow simplify integration into existing aftermarket or factory installed (OEM) integrated entertainment systems so you can connect your OEM unit (or any unit that doesn’t have the typical RCA-type inputs) without having to buy add-on adapters. So, the install goes faster, you save money, and you’ve got a Pioneer amp in your vehicle.

Product Specification:

• 5 Channel Champion Series Class D Amplifier w/ Wired Bass Boost Remote
• Max Power Rating:
• 4 ohms: 150 watts x 4 chan. + 700 watts x 1 chan.
• 2 ohms: 200 watts x 4 chan. + 1200 watts x 1 chan.
• Bridged, 4 ohms: 400 watts x 2 chan.
• RMS Power Rating:
• 4 ohms: 75 watts x 4 chan. + 350 watts x 1 chan.
• 2 ohms: 100 watts x 4 chan. + 600 watts x 1 chan.
• Bridged, 4 ohms: 200 watts x 2 chan.
• Total power output: 2000 watts Max
• CEA-2006 Compliant Amplifier
• Pulse Width Modulated MOSFET power supply
• Wired remote bass boost level control included
• LED power (green) and protect (red) indicators
• Soft start turn-on
• Speaker-level (high-level) inputs
• 5, 4 or 3 channel operation
• Dedicated, large-block subwoofer terminal output
• Nickle-plated RCA, Speaker and Power/Ground Terminals
• Selectable input modes:
• Front two channels (RCA Only) can provide signal to remaining channels
• Four channel High-Level connection can provide signal to Subwoofer channel
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Heavy duty aluminum alloy heat-sink for extreme heat dissipation
• Input sensitivity:
• Low level: 200mV – 6.5V
• High level: 800mV – 16V
• A/B Channel Frequency Response: 10 – 50,000 Hz (+0dB, -3dB)
• Sub-Channel Frequency Response: 10 – 500 Hz (+0dB, -3dB)
• Total Harmonic Distortion (THD): 0.05%
• Signal to Noise Ration: 94 dB
• Selectable crossover filter (Ch 1 – 4): LPF / OFF / HPF
• Variable crossover filter (Ch 1 – 4): 40 – 500 Hz, 12 dB/octave
• Variable low-pass filter (Sub): 40 – 500 Hz, 24 or 12 dB/octave
• Variable Bass Boost (Via Remote): 0 to +18 dB bass boost at 50 Hz
• Fuse Rating: 30A x 3
• 8 – 16 Gauge speaker terminal outputs
• 4 gauge power and ground wiring is recommended for installation.
